QAM2110.040 Duct temperature sensor 400 mm Pt100
QAM2110.040 - Duct temperature sensor 400 mm, Pt100
| Product | ||
| Article Number (Market Facing Number) | QAM2110.040 | 100325772 | |
| Product Description | QAM2110.040 - Duct temperature sensor 400 mm, Pt100 | |
| Product Lifecycle (PLM) | PM300:Active Product | |
| Price data | ||
| Price Group / Headquarter Price Group | U1 / U1 | |
| Metal Factor | None | |
| Delivery information | ||
| Export Control Regulations | AL : N / ECCN : N | |
| Factory Production Time | 1 Day/Days | |
| Net Weight (kg) | 0.171 Kg | |
| Product Dimensions (W x L x H) | Not available | |
| Packaging Dimension | 8.50 x 21.10 x 7.30 | |
| Package size unit of measure | CMT | |
| Quantity Unit | 1 Piece | |
| Packaging Quantity | 1 | |
| Additional Product Information | ||
| EAN | 7612914073457 | |
| UPC | Not available | |
| Commodity Code | 85332100000 | |
| LKZ_FDB/ CatalogID | BT_Catalog | |
| Product Group | QBE1 | |
| Country of origin | China | |
| Compliance with the substance restrictions according to RoHS directive | Since: 2008.05.07 | |
| Product class | Not available | |
| WEEE (2012/19/EU) Take-Back Obligation | Yes | |
| REACH Art. 33 Duty to inform according to the current list of candidates |
|
|
| Classifications | ||
| Not available | ||
QAM2110 QAM2112 QAM2120 QAM2130 Duct temperature sensor, passive
Stock no. BPZ:QAM21..0..
Fully active, flexible probe for averaging.
Additional info
Note on fixing:
Supplied complete with mounting flange.
|
Attribute |
Value |
|
Time constant |
At v = 2 m/s: 30 s |
|
Connection, electrical |
Screw terminals |
|
Type of fixing |
Flange |
|
Degree of protection |
IP42 |
|
Dimensions (W x H x D) |
80 x 61 x 31 mm |
Product Variants
QAM2110.040 - Duct temperature sensor 400 mm, Pt100
QAM2112.040 - Duct temperature sensor 400 mm, Pt1000
QAM2112.200 - Duct temperature sensor 2000 mm, Pt1000
QAM2120.040 - Duct temperature sensor 400 mm, LG-Ni1000
QAM2120.200 - Duct temperature sensor 2000 mm, LG-Ni1000
QAM2120.600 - Duct temperature sensor 6000 mm, LG-Ni1000
QAM2130.040 - Duct temperature sensor 400 mm, NTC 10k
