VVF63 High-performance valves Valve body PN40
VVF63 2-port valve, PN 40, DN 125, kvs 200, with flanged connections
- With flanged connections to ISO 7005
- For cooling, chilled, low and high temperature water, brine, heat transfer oils, saturated and superheated steam in open and closed circuits
Technical Specifications
Stroke 40 mm
Leakage rate 0...0.01 % of kvs
DN 15-125
Medium temperature -20…220 °C
Valve characteristic Equal percentage
Rangeability Fluids: > 100 , Steam: > 50
Permissible operating pressure 4000 kPa
Material, valve body Cast iron ASTM A216WCB (GP240GH)
Material, inside set Stainless steel
PN class PN 40
| Material No | Article Type |
Material Description (En) |
| S55210-V100 | VVF63.15-0.2 | VVF63.15-0.2 2-Port ValvePN40flanged |
| S55210-V101 | VVF63.15-0.32 | VVF63.15-0.32 2-Port ValvePN40flanged |
| S55210-V102 | VVF63.15-0.5 | VVF63.15-0.5 2-Port ValvePN40flanged |
| S55210-V103 | VVF63.15-0.8 | VVF63.15-0.8 2-Port ValvePN40flanged |
| S55210-V104 | VVF63.15-1.25 | VVF63.15-1.25 2-Port ValvePN40flanged |
| S55210-V105 | VVF63.15-2 | VVF63.15-2 2-Port ValvePN40flanged |
| S55210-V106 | VVF63.15-3.2 | VVF63.15-3.2 2-Port ValvePN40flanged |
| S55210-V107 | VVF63.20-6.3 | VVF63.20-6.3 2-Port ValvePN40flanged |
| S55210-V108 | VVF63.25-5 | VVF63.25-5 2-Port ValvePN40flanged |
| S55210-V109 | VVF63.25-8 | VVF63.25-8 2-Port ValvePN40flanged |
| S55210-V110 | VVF63.32-16 | VVF63.32-16 2-Port ValvePN40flanged |
| S55210-V111 | VVF63.40-12.5 | VVF63.40-12.5 2-Port ValvePN40flanged |
| S55210-V112 | VVF63.40-20 | VVF63.40-20 2-Port ValvePN40flanged |
| S55210-V113 | VVF63.50-31.5 | VVF63.50-31.5 2-Port ValvePN40flanged |
| S55210-V115 | VVF63.80-80 | VVF63.80-80 2-Port ValvePN40flanged |
| S55210-V115-A115 | VVF63.80-80F | VVF63.80-80F 2-Port ValvePN40flanged |
| S55210-V116 | VVF63.100-125 | VVF63.100-125 2-Port ValvePN40flanged |
| S55210-V116-A115 | VVF63.100-125F | VVF63.100-125F 2-Port ValvePN40flanged |
| S55210-V117 | VVF63.125-200 | VVF63.125-200 2-Port ValvePN40flanged |
| S55210-V119 | VVF63.50-40K | VVF63.50-40K 2-Port ValvePN40flanged |
| S55210-V120 | VVF63.65-63K | VVF63.65-63K 2-Port ValvePN40flanged |
| S55210-V121 | VVF63.80-100K | VVF63.80-100K 2-Port ValvePN40flanged |
| S55210-V122 | VVF63.100-150K | VVF63.100-150K 2-Port ValvePN40flanged |
| S55210-V124 | VVF63.150-315K | VVF63.150-315K 2-Port ValvePN40flanged |
| S55210-V130 | VVF63.25-8L | VVF63.25-8L 2-Port ValvePN40flanLed |
