QAM2112.040 Duct temperature sensor 400 mm Pt1000

QAM2112.040 - Duct temperature sensor 400 mm, Pt1000

Product
Article Number (Market Facing Number) QAM2112.040  | 100546213
Product Description QAM2112.040 - Duct temperature sensor 400 mm, Pt1000
Product Lifecycle (PLM) PM300:Active Product
Price data
Price Group / Headquarter Price Group U1 / U1
Metal Factor None
Delivery information
Export Control Regulations AL : N / ECCN : N
Factory Production Time 1 Day/Days
Net Weight (kg) 0.167 Kg
Product Dimensions (W x L x H) Not available
Packaging Dimension 8.80 x 20.80 x 7.00
Package size unit of measure CMT
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN 7612914073440
UPC Not available
Commodity Code 853321
LKZ_FDB/ CatalogID BT_Catalog
Product Group QBE1
Country of origin China
Compliance with the substance restrictions according to RoHS directive Since: 2007.10.30
Product class Not available
WEEE (2012/19/EU) Take-Back Obligation Yes
REACH Art. 33 Duty to inform according to the current list of candidates

Reach Information
Classifications
  Not available

QAM2110 QAM2112 QAM2120 QAM2130 Duct temperature sensor, passive

Stock no. BPZ:QAM21..0..

Fully active, flexible probe for averaging.

Additional info

Note on fixing:

Supplied complete with mounting flange.

Attribute

Value

Time constant

At v = 2 m/s: 30 s

Connection, electrical

Screw terminals

Type of fixing

Flange

Degree of protection

IP42

Dimensions (W x H x D)

80 x 61 x 31 mm

Product Variants

QAM2110.040 - Duct temperature sensor 400 mm, Pt100

QAM2112.040 - Duct temperature sensor 400 mm, Pt1000

QAM2112.200 - Duct temperature sensor 2000 mm, Pt1000

QAM2120.040 - Duct temperature sensor 400 mm, LG-Ni1000

QAM2120.200 - Duct temperature sensor 2000 mm, LG-Ni1000

QAM2120.600 - Duct temperature sensor 6000 mm, LG-Ni1000

QAM2130.040 - Duct temperature sensor 400 mm, NTC 10k
